Garrett G25-660 Turbocharger 54mm
$845.00 – $3,399.00
FREE SHIPPING
Ships in 2 – 3 days
Description
Garrett G25-660 Turbocharger 54mm
As the most compact turbo frame offered from the Garrett G Series, the G25-660 offers the opportunity to make up to 500 wheel horsepower without sacrificing the responsiveness of a small frame turbo. As such, this is a popular turbo for SR20 and CA18 applications.
Generally, we would recommend the G25-660 turbocharger for SR20DET set ups currently running a T25 or T28 who are looking to upgrade/increase their horsepower up to 500 wheel horsepower. If your goals for your 4-cylinder are beyond 500 wheel horsepower, the next step up in turbos is the G30 range, starting with the 660.
- Standard Rotation
- External Wastegate
- 1.4L – 3.0L engine displacements
- 350HP – 660HP
- V-Band
- 0.72 A/R or 0.92 A/R
The G25-660 is also available in reverse rotation, click here to shop!
Turbocharger Options
Choose to purchase a supercore with an exhaust housing or just the supercore or exhaust housing on it’s own! Please contact us for internally wastegated options.
- 0.72 A/R, V-Band / V-Band (858161-5003S + 740902-0069)
- 0.92 A/R, V-Band / V-Band (858161-5003S + 740902-0068)
- G25-660 Standard Rotation Supercore ONLY (858161-5003S)
- 0.72 A/R, V-Band / V-Band Exhaust Housing ONLY (740902-0069)
- 0.92 A/R, V-Band / V-Band Exhaust Housing ONLY (740902-0068)
Garrett G25-660 Features:
- Ceramic Dual Ball Bearing
- Stainless Steel Turbine Housing
- High Temperature Resistant
- Compressor Inducer: 54mm
- Compressor Exducer: 67mm
- Compressor Trim: 65
- Compressor A/R: 0.70
- Turbine Inducer: 54mm
- Turbine Exducer: 49mm
- Turbine Trim: 84
Understanding the Name:
G Series turbocharger
25 classifies the size of the frame
660 identifies the maximum crank horsepower rating of the turbocharger
The proof is in the pudding! We have tried and tested the G Series range of turbos on almost every in house build including HYPGAME, ONE2RUN, STCHDUP and more! If you’re looking for the best turbo upgrade for your JDM performance engine, you can’t look past a Garrett turbo.
If you are looking for a 500HP turbo and are unsure if this is the right turbo for your application and power goals, give us a call on 07 4602 3858!
